NS1 NanoSpinner Electrospinning/Spraying Equipment


Brief Description

The NS1 model includes all the basic components required for electrospinning operations: syringe pump, high voltage power supply, and collector parts. It is possible to apply high voltage with precision as well as adjust the flow rate and the distance between the needle and collector.
The spinning area is not enclosed in a cabinet, but the small size of the system allows it to fit inside a fume hood.

Optional Accessories

Different Diameter Needles

Electrospinning needles with the following diameters: (23G, 21G, 19G, 17G, 15G) X10 pieces.

Bicomponent System

Two special designed coaxial nozzles:
Shell Nozzle
(ID : 0.337 mm, OD: 3.3 mm)
Core nozzle
(ID: 0.6414 mm, OD: 1 mm)
and an extra syringe pump to obtain core-shell, hollow and bicomponent nanofibers.

Gas Shield Nozzle

Gas Shield is a way to solve clogging of polymer on the top of needle by solvent saturated N2 gas. This option may increase productivity of many polymer solutions.

Extended Warranty

Standard Devices come with 1 year warranty. In addition, it is possible to cover machine with extended warranty.
